B04
>> Back to Products List
No. |
Part |
Material |
Qty |
No. |
Part |
Material |
Qty |
1 |
Stem |
U-PVC |
1 |
7 |
O-Ring |
EPDM |
2 |
2 |
Handle |
ABS |
1 |
8 |
Body |
PVC |
1 |
3 |
Stem O-Ring |
EPDM |
2 |
9 |
Ball |
PVC |
1 |
4 |
Union Nut |
U-PVC |
2 |
10 |
Seat Seal |
PTEE |
2 |
5 |
End Connector |
U-PVC |
2 |
11 |
Seat Carrier |
PVC |
1 |
6 |
Body O-Ring |
EPDM |
2 |
12 |
Carrier O-Ring |
EPDM |
1 |
DIMENSIONS – Diameter |
d1 |
d2 |
D1 |
D |
I |
L1 |
L2 |
H |
PN |
20 |
14 |
26 |
50 |
22 |
100 |
65 |
53 |
10 |
25 |
19 |
31 |
66 |
22 |
113 |
80 |
59 |
10 |
32 |
24 |
38 |
74 |
24 |
113 |
85 |
68 |
10 |
40 |
32 |
49 |
87 |
29 |
127 |
97 |
79 |
10 |
50 |
40 |
61 |
102 |
34 |
144 |
117 |
94 |
10 |
63 |
45 |
74 |
120 |
40 |
162 |
134 |
106 |
10 |
75 |
60 |
88 |
135 |
44 |
224 |
161 |
113 |
10 |
90 |
80 |
105 |
189 |
54 |
267 |
200 |
144 |
10 |
110 |
100 |
132 |
216 |
83 |
306 |
240 |
164 |
10 |
